Kitchen Cabinet Planning: How to Lay Out and Load Your Cabinets

You can repaint a kitchen, swap the hardware, or replace the countertops years later without much disruption. The cabinet layout is different. The boxes are built to fit your appliances and your walls down to the inch. Once they're ordered, even a small change can mean redoing the whole plan. So kitchen cabinet planning starts with the decisions you can't undo, and leaves the finishes for last.

Most people split the job into two parts: where the cabinets go (the kitchen cabinets layout) and what goes inside them (the organization). The two work better as one plan. The size and type of each cabinet should follow from what it will hold. These decisions also come in a set order. Follow that order instead of copying a layout you saw online, and you avoid the change orders that come from working backward.

Settle the layout decisions you can't take back first

Three things get locked before any cabinet is drawn: the appliances, the venting, and the order you buy in. Handle them in that sequence.

Start with the appliances and plumbing

The first round of choices doesn't involve cabinets yet. You settle the appliances and the plumbing first, because every cabinet around them gets sized to fit. A 36 inch range and a 30 inch range need different openings. A counter-depth refrigerator sits flush with the boxes, while a standard one sticks out past them. If you want a fridge that blends into the cabinetry, the cabinetmaker needs to know before anything is cut, since those panels are part of the cabinet order.

Sort out the venting

Venting is the part people forget. A range hood needs a duct path to an outside wall or the roof, and that route can run right through the spot you wanted for a tall pantry. Decide whether you're getting a ducted hood, a venting microwave, or a downdraft before you finalize the cabinet plan.

Order cabinets in the right sequence

Timing is where people get tripped up. Cabinets have the longest lead time. Semi-custom lines often run 6 to 12 weeks out, and fully custom takes longer. So you need to order them early in the project. But the cabinet sizes depend on the appliances, so you have to choose the appliances even earlier. Pick the models, get their exact specs, then order cabinets built around them.

Cabinets are usually the biggest single line in a kitchen budget, so swapping a fridge or range after they're cut means paying for them twice.

Design a Home That’s Uniquely Yours

Block can help you achieve your renovation goals and bring your dream remodel to life with price assurance and expert support.

Get Started

Shape your kitchen cabinets layout around how you cook

Most planning articles list the same six shapes (one-wall, galley, L-shaped, U-shaped, island, and peninsula) and tell you to pick one. It works better to let the shape come last. Two things you already have should decide it: the room itself, and the way your household moves through a meal.

The old shortcut for that movement is the work triangle. It connects the sink, the stove, and the refrigerator and keeps them close together. The idea was built for a 1940s kitchen with one cook and three appliances. Many kitchens now have two cooks, a separate prep sink, a microwave drawer, a coffee station, and an island people sit at. A single triangle can't account for all of that.

A more useful approach is to think in zones. Think of the kitchen as a set of stations, and give each one its own counter space and cabinets:

• Prep zone. A counter run near the sink, with a trash pull-out and the knives, boards, and mixing bowls in the cabinets right there.
• Cooking zone. The range or cooktop, with pots, pans, oils, and spices within a step.
• Cleanup zone. The sink and dishwasher, with everyday dishes and glasses in the cabinet you can reach while unloading.
• Storage zone. The pantry and the bulk of dry goods, which can sit further out since you visit it less often.

Once the zones fit the room you have, the shape is usually obvious. Two runs facing each other across an aisle read as a galley. An L is just those same zones bent around two adjoining walls.

Match your kitchen cabinet organization layout to what you'll store

This is where your kitchen cabinet organization layout comes together. What lives inside each cabinet should decide its size, depth, and type. That means you plan the loading and fill out the order form at the same time.

Drawers beat doors for almost anything heavy or stacked. A base cabinet with a door and a fixed shelf buries whatever ends up in the back. Three deep drawers in the same width put pots, lids, and small appliances within easy reach. Save the door-and-shelf base cabinets for the few tall items that don't fit drawers well, like sheet pans and cutting boards stood on edge.

Keep everyday items within reach of where you actually use them.

• Plates and glasses go next to the dishwasher, so unloading is one turn instead of a lap of the room.
• Spices and cooking oils belong in a pull-out or a shelf right beside the range.
• A blender you reach for a few times a year can go on a high shelf or in the awkward corner.

For anything that won't fit at arm height, reach for the space overhead. Running the cabinets to the ceiling turns the dead space above standard uppers into real storage for the platters and seasonal gear you only pull down a few times a year.

Plan the corner before it eats your storage

Corners quietly fail in a lot of layouts. Where two cabinet runs meet, a standard corner base can strand close to 9 square feet. You can see the space behind the face frame, but you can't reach it.

Only a few fixes work, and you have to build each one into the plan from the start:

• A lazy Susan that rotates the whole corner out to you, best for pots and bulk items.
• A blind-corner pull-out that slides the hidden shelves into the light, better where a Susan won't fit the cabinet faces you want.
• A diagonal corner cabinet that gives up a little counter to make the inside fully usable, often paired with the sink.

Pick one early. The corner solution changes the cabinet widths on both runs that meet there. Leave it until install day, and you'll either pay for a custom fix or live with the dead zone.

We asked Mel Stutzman, a former cabinet maker and the owner of Countryside Amish Furniture, where homeowners most often go wrong with corners.

The corner is the part homeowners always underplan. A standard corner cabinet sends a big stretch of shelf back into the dark where you can't reach it, so you end up paying for storage you never really use. A lazy Susan or a pull-out fixes that, but you have to call it before the cabinets are built.

– Mel Stutzman, Owner, Countryside Amish Furniture

More cabinets isn't the goal

It's tempting to treat wall space as something to fill, lining every inch with uppers because the space is there. But once everything you own has a home, more cabinets just sit empty. A window, a stretch of open wall, or open shelves or no upper doors at all can do more for how the room feels than another bank of doors. If you do need more storage, the better move is usually to extend the uppers to the ceiling on the runs you already have instead of covering a fresh wall.

Check cabinet clearances before you commit to a layout

A plan can look right on paper and still be too tight to cook in. Before you sign off, check it against the standard clearances kitchen designers follow. They keep doors, drawers, and people from colliding.

Aisle width matters most. A walkway with no work on either side needs at least 36 inches. A work aisle, where someone opens an oven or dishwasher, needs at least 42 inches for one cook and 48 inches for two. Go tighter than that, and two people can't pass while the oven door is down.

Then check the landing counters, the open surface beside each spot where you set things down:

If you still want a triangle, the standard guidelines put each leg between 4 and 9 feet, with the three legs adding up to less than 26 feet and no main walkway cutting through the middle. Check your plan against these numbers before the order goes in, while changes still cost nothing.

Common kitchen cabinet layout mistakes

Most layout problems trace back to a handful of errors that show up on job after job. Catch them on the plan, while a fix still costs nothing.

• Leaving the corner for last. A standard corner cabinet strands space you can't reach, and the fix changes the widths of both runs that meet there. Settle on a lazy Susan, a blind-corner pull-out, or a diagonal cabinet before you order.
• Choosing door cabinets where drawers would serve better. A door-and-fixed-shelf base buries whatever lands in the back. Deep drawers in the same width keep pots, lids, and small appliances in easy reach.
• Lining every wall with uppers. Once everything has a home, extra cabinets sit empty and close the room in. Leave a window or a stretch of open wall, or run the cabinets you already have up to the ceiling.
• Doors and drawers that collide. Two cabinet doors opening into the same space, an oven door swinging toward the island, or a dishwasher that blocks a corner cabinet all make daily work harder. The dishwasher next to a corner is the one people miss most, since its open door and the corner cabinet fight for the same standing room.
• No home for trash and recycling. Skip it and a freestanding bin ends up in the walkway. Build a pull-out into the prep or cleanup zone from the start. A double pull-out keeps trash and recycling together and frees up the floor.
• Setting cabinets tight to a wall with no filler. An end cabinet or drawer pushed against the wall can't clear the trim or the next door over. A narrow filler strip gives the doors and drawers room to open.
