How to Obtain a Blueprint of Your Home

Moving a wall, adding a bathroom, or finishing a basement all start with the same question from a contractor or architect: do you have plans for the house? Most homeowners do not, and the ones who think they do usually have a marketing floor plan from the old listing rather than a real drawing set. The original plans often still exist, though, because a copy was filed with a government office the day the building permit was pulled. Knowing how to obtain a blueprint of your home can save you the $700 to $2,500 a professional charges to measure the place and redraw it from scratch.

How hard the search gets depends on when the house was built and which office holds the file. A 2015 subdivision home in a mid-size city is usually a records request and a small copy fee. A 1908 rowhouse in a city that never microfilmed its early permit records is a longer hunt, and it can still end with you hiring someone to draw a new set.

Finding your home's blueprints: quick overview

• Start with your local building department, which holds the drawing set filed when your house was built or altered.
• Expect to prove ownership and to clear a copyright review, because the architect who drew the plans still holds the rights to them.
• Pull your county assessor's property record card early, since it is free in most counties and often carries a rough footprint sketch.
• Treat any set you recover as the approved design rather than the finished house, and verify dimensions on site.
• Ask the county recorder for plats and surveys when the original drawings are gone.
• Call the builder or architect directly if the house is under about 30 years old and the firm is still operating.
• Search historical archives and local library collections for houses built before roughly 1940.
• Budget $700 to $2,500 for a new set of as-built drawings if nothing usable survives.
• Plan on new stamped drawings for any permit application, since the original set will not satisfy a plan reviewer.

Not sure how to begin your renovation?

Get free, expert guidance from a dedicated Block Project Planner who can help you navigate proposals, timelines, contractor selection, and more.

Book A Free Consultation

What people mean when they say "blueprint"

The word is a holdover. True blueprints were cyanotype prints, white lines on blue paper, and the process fell out of use by the 1950s. What you are actually looking for is a construction drawing set: floor plans, elevations, sections, and framing details that show how the house was built.

If your goal is a renovation, you want the permit set.

Request the permit file from your local building department

When anyone pulls a permit for new construction, an addition, or a structural change, they submit a full drawing set for plan review, and that set goes into the property file. Most departments keep those files indefinitely on microfilm or in a digital archive, indexed by address or parcel number.

Larger jurisdictions have an online portal where you can pull permit history yourself and order copies of the plans attached to each permit. Smaller ones want an email, a form, or a visit to the counter.

What to have ready when you ask

Have the parcel number, not just the address. Records are indexed by parcel or lot in most systems, and addresses change more often than parcels do. Your annual property tax bill lists it near the top, and if you cannot put your hands on the bill, NACo's county lookup will point you to the assessor's office that assigned it.

Know roughly when the work was done. Clerks search by permit year, so "the house was built in 1994 and the addition went on around 2006" narrows a search that would otherwise cover three decades of microfilm.

Bring proof that you own the house. Many departments require a recorded grant deed or a tax statement before they release residential plans, particularly if the county records still show the previous owner.

Ask specifically what the department retained. Plenty of cities keep permit cards and inspection records forever but discard the drawings after a set number of years, and some never retained plans for remodels or additions at all. Getting that answer up front saves you a fee and a wait.

What the fees usually run

Inspection at the counter is typically free. For example, Martin County, Florida, charges nothing for building records sent by email and $1 for a disk, with paper copies priced by size and quantity. Rancho Palos Verdes, California, requires a $500 trust deposit before staff will begin the research, plus the reproduction fee on top of it, because state law puts the city in the middle of a formal copyright notification process.

Budget roughly $10 to $75 for a scanned set and $5 to $20 per sheet for large-format prints, since a full residential set runs 8 to 15 sheets.

Retention rules can matter more than fees. Florida requires residential building plans to be kept for 10 anniversary years after the certificate of occupancy is issued, so a house finished in 1998 may have nothing left in the file no matter what you are willing to pay for it.

Why the city may let you look but not copy

Building plans are generally public records you can inspect, but the drawings themselves are copyrighted works owned by the architect or engineer who drew them. Filing a set with a government agency for permit review does not transfer that copyright. So a department can let you sit at the counter and read the plans while still refusing to hand you a copy.

In California, cities follow a duplication procedure under Health and Safety Code Section 19851: the owner signs a notarized affidavit, the city sends a certified letter to the licensed professional who stamped the plans, and that professional has 30 days to respond before the city can release copies. Other states handle it less formally, and some departments will simply hand over a scan for anyone who owns the property.

The 30-day notification window is where most of the delay sits, and two things can shorten it:

• Say so in the request if the design professional has died or the firm has dissolved. Most duplication procedures have a path for that, and flagging it up front keeps your file out of a 30-day waiting period for a letter nobody will answer.
• Ask whether you can photograph the plans at the counter. Some departments allow it even when they will not issue copies, though others, San Diego among them, specifically prohibit photographing, tracing, or sketching plans during a viewing.

Renovate with confidence every step of the way

Step 1: Personalize Your Renovation Plan

Step 2: Receive Quotes from Trusted Contractors

Step 3: Let Us Handle the Project Details

Get Started

Other places the original plans turn up

The builder or architect

Production builders and architecture firms keep project archives, sometimes for decades. If your house is under 30 years old and the company is still operating, a call to their office is worth an afternoon.

Be ready for a no. National homebuilders often treat their floor plans as proprietary and decline to release full construction drawings to homeowners. When that happens, ask whether they will send the marketing plan for your model instead. It will not show framing or mechanical runs, but it gives you accurate room dimensions and a starting point for a designer.

A neighbor with the same model

In tract developments, a small number of plans were built dozens of times across the subdivision. A neighbor with the same elevation may have the drawing set, and for most planning purposes their copy answers your questions about span directions, bearing walls, and ceiling framing. Verify anything structural on site, since mirrored lots and mid-run plan revisions are common.

County recorder, assessor, and plat books

Counties index property by parcel rather than by permit, which is why their records often outlive the building department's:

• The recorder's office keeps deeds and, in many counties, subdivision plats showing lot lines and original building envelopes
• The assessor's office keeps property record cards, and in many counties those cards carry a rough footprint sketch with exterior dimensions and square footage by floor
• The clerk's office may hold plat books that name the developer or builder, which gives you a lead to chase

None of these is a construction drawing, and an assessor's sketch has real limits: it is drawn for valuation rather than design, it shows the exterior outline without interior walls, and the dimensions are approximate. Pull it first anyway. Availability varies by county, but where it exists it is usually free and online, and a rough footprint gives your architect something to work from while a records request moves through the queue.

Historical archives, for older houses

Houses with any architectural or historical significance may be documented in the Historic American Buildings Survey, a National Park Service program running since 1933. The collection now holds more than 581,000 measured drawings, photographs, and written histories covering over 43,000 structures, digitized and searchable through the Library of Congress.

County historical societies, university architecture libraries, and public library local-history rooms often hold builder catalogs, pattern books, and original developer plan sets for entire neighborhoods. Sanborn fire insurance maps, widely digitized, will not give you interior layouts, but they confirm footprint, construction type, and the number of stories at a given date, which helps you date additions.

What the original set can and cannot tell you

A permit set documents the design a plan reviewer approved, which is not always the house that got built. Field changes happen during construction, and only some of them get redlined back into the copy on file. Add whatever the last two owners changed without pulling a permit, and the gap widens further.

• Trust it on structure and systems. Framing direction, bearing walls, header locations, and the position of plumbing stacks and duct chases rarely move once a house is standing, and knowing them early is what keeps a design from getting redrawn after demolition.
• Verify dimensions on site. Room sizes, ceiling heights, and rough openings are worth confirming with a tape measure before anyone designs to them, particularly in a house that has been remodeled.
• Check the sheet dates before you trust a drawing. Sets get revised during plan review, and the version sitting in the file is not always the last one issued, so compare dates and revision blocks across the sheets.

An architect who starts with accurate load paths and a verified footprint spends less of your money working out what sits behind the walls.

Paying to have a new set drawn

A 1962 ranch that has been through two kitchen remodels and a rear addition is not accurately represented by its 1962 permit set, and a contractor bidding off those drawings will price the wrong project.

In that case you commission as-built drawings, which document the house as it stands today. The process is straightforward: someone measures the interior and exterior, notes ceiling heights and window and door locations, and produces a scaled drawing set in CAD. Set the price against what a whole-house renovation costs before you decide to skip it, because documentation is one of the smaller line items in the budget and one of the few that reduces risk everywhere else.

• As-built drawings for a typical single-family home run about $700 to $2,500. Priced by area, that is roughly $0.50 to $2.50 per square foot, depending on size, complexity, and how much detail you need.
• A drafter costs less than an architect for pure documentation. Drafting services generally bill $50 to $125 per hour, and measuring a 2,500 square foot house takes most of a day.
• Laser scanning costs more and delivers more. A LiDAR or SLAM scan produces a point cloud of the whole house, which is valuable for irregular older homes where nothing is square.
• Full remodel plan sets are a separate service. Architect fees for residential plans-only work commonly land between $2,500 and $20,000 based on scope, and as-built documentation is usually the first phase of that fee rather than an add-on.

If a renovation is already in motion, ask your architect or design-build contractor whether as-builts are included in their proposal. Often they are, and paying for a standalone set first duplicates the work. If you have not hired anyone yet, ask about documentation while you are still choosing an architect, since firms handle it differently and the answer belongs in the fee comparison.

Design a Home That’s Uniquely Yours

Block can help you achieve your renovation goals and bring your dream remodel to life with price assurance and expert support.

Get Started

What your renovation actually requires

Original blueprints are helpful for planning, but they are not what your city will approve.

Permit applications for structural work, additions, or anything touching mechanical systems require current drawings that reflect the proposed conditions, and in most jurisdictions those drawings need a licensed architect's or engineer's stamp. Handing the plan reviewer a 1994 set with pencil marks will not get you a permit.

The original plans matter most earlier, during design and bidding. They tell your architect which walls carry load, where the plumbing stacks run, and how the roof is framed, and every one of those answers reduces the guesswork that turns into change orders once demolition starts. They also help contractors bid more accurately, because a bidder who can see the framing does not have to price the worst case. That accuracy gives you something concrete to work with when you negotiate with a contractor over line items in the scope.

For smaller projects, you may not need plans at all. A bathroom remodel inside existing walls, a kitchen refresh with no layout change, or new flooring will not require a drawing set in most jurisdictions, and the question becomes whether the job warrants hiring a general contractor or a single trade.
